WS-PII56(65)4L-xD -
WS-PII56(65)4L-xD
10GBASE-LR/LW Other optical links
Hot Pluggable
Single LC interface, Duplex operation
1270nm/1330nm DFB transmitter, PIN receiver
Operating case temperature: 0 to 70 °C
Power consumption <1W
Applicable for 40km SMF connection
Single +3.3V power supply
All-metal housing for superior EMI performance
Cost effective SFP+ solution, enables higher port densities and greater bandwidth
RoHS compliant (lead free)
WS-PII56(65)4L-xD (10Gbs 40km SFP+ T1270&1330nm R1330&1270nm).pdf
Transmitter Electrical Characteristics | |||||
Parameter | Symbol | Min | Typ | Max | Unit |
Differential Input Voltage Swing | VIN | 180 | - | 700 | mV |
Tx Differential Input Impendence | ZIN | - | 100 | - | Ω |
Transmitter Disable Voltage | VDIS | 2.0 | - | VCC+0.3 | V |
Transmitter Enable Voltage | VEN | 0 | - | 0.8 | V |
TFAULT Logic High | VTFH | 2.4 | - | VCC | V |
TFAULT Logic Low | VTFL | VEE | - | VEE+0.4 | V |
Receiver Electrical Characteristics | |||||
Parameter | Symbol | Min | Typ | Max | Unit |
Differential output Voltage Swing | VOUT | 300 | - | 850 | mV |
Rx Differential Output Impendence | ZOUT | - | 100 | - | Ω |
LOS Assert Voltage | VLOSA | 2.4 | - | VCC | V |
LOS De-assert Voltage | VLOSD | VEE | - | VEE+0.4 | V |
<td width="234" valign="center" style="padding: 0px; border-left-width: 1px; border-left-color: rgb
Parameter | Symbol | Min | Typ | Max | Unit | Notes |
Transmitter Characteristics | ||||||
Laser Type | DFB | |||||
Center Wavelength(WS-PII564L-XX) | λ | 1260 | 1270 | 1280 | nm | |
Center Wavelength(WS-PII654L-XX) | λ | 1320 | 1330 | 1340 | nm | |
Spectral Width@-20dB | Δλ | - | - | 1 | nm | |
Side Mode Suppression Ratio | SMSR | 30 | - | - | dB | |
Launch Optical Power | Pout | 1 | - | 6 | dBm | <span style="font-family: Arial;color: rgb(0, 0, 0);letter-spacing: -1px;fon
